Chapter 2: Front panel programming
92 Vigilant VS1 and VS2 Technical Reference Manual
Option Description
NACs connected to the panel.
Smoke: For modules wired to a Class B circuit composed only of four-wire
smoke detectors. Modules with this device type trigger active (alarm) events.
Smoke Class A: For modules wired to Class A circuits composed only of four-
wire smoke detectors. Modules with this device type trigger active (alarm)
events.
Supervised Output: For modules wired to Class B circuits that output an
unsynchronized signal that does not turn off when you press Signal Silence.
Supervised output Class A: For modules wired to Class A circuits that output
an unsynchronized signal that does not turn off when you press Signal Silence.
Supervised output Class A (latched): For latched output modules wired to Class
A circuits that output an unsynchronized signal that does not turn off when
you press Signal Silence.
Supervised output (latched): For latched output modules wired to Class B
circuits that output an unsynchronized signal that does not turn off when you
press Signal Silence.
Supervised output Class A: For modules wired to Class A circuits that output
an unsynchronized signal that does not turn off when you press Signal Silence.
Supervisory latching: For supervisory devices. Momentary activation of
normally open devices immediately places the panel in a supervisory state
and turns on supervisory LEDs and relays. Circuit cannot be restored until
devices are restored to normal and the panel is reset.
Supervisory Latching Class A: For modules wired to Class A circuits composed
only of supervisory switches. Modules with this device type trigger active
(supervisory) events. The module remains active until the condition that
activated it is restored and the control panel is reset.
Supervisory nonlatching: For supervisory devices. Momentary activation of
normally open devices immediately places the panel in a supervisory state
and turns on the supervisory LED and relay. Annunciation remains active until
the input restores. The panel does not have to be reset.
Supervisory Non-latching Class A: For modules wired to Class A circuits
composed only of supervisory switches. Modules with this device type trigger
active (supervisory) events. The module remains active until the condition that
activated it is restored. Resetting the control panel is not required.
Unlatch outputs: For Class A or B Signature input module circuits used to
unlatch all latched outputs. The following output modules can be configured
to unlatch latched outputs: SIGA-CT1, SIGA-CT2, SIGA-MAB, SIGA-MCT2,
SIGA-MM1, and SIGA-UM.
Visible: For NACs connected to visible notification appliance that do not turn
off when Signal Silence is pressed.
Waterflow: For connecting vane type and pressure flow switches. Activations
are considered as alarms. A 16-seconddelay applies to waterflow device
types. NACs activated by waterflow device types cannot be silenced until the
activated devices are restored to normal via a panel reset. Circuit cannot be
restored until devices are restored to normal and the panel is reset. Waterflow
