Chapter 2: Front panel programming
Vigilant VS1 and VS2 Technical Reference Manual 93
Option Description
activations do not invoke in-suite signal silence.
Water Flow Class A: For modules wired to Class A circuits composed only of
waterflow alarm switches. Modules with this device type initiate active (alarm)
events if the circuit remains shorted for at least 16 seconds. NACs activated by
waterflow device types cannot be silenced until the activated devices are
restored to normal via a panel reset. Circuit cannot be restored until devices
are restored to normal and the panel is reset. Waterflow activations do not
invoke in-suite signal silence.
Relay module
Relay nonsilence: For relay devices that do not follow signal silence.
Relay with silence: For relay devices that follow signal silence.
Latched outputs
Supervised Outputs (Latched) — SupOut Latch: For Class B latched output
modules that output an unsynchronized signal. Does not follow signal silence.
Continuous Non-Silenceable (Latched) Cont NS Latch: For Class B latched
output modules that output an unsynchronized signal. Does not follow signal
silence.
Continuous Non-Silenceable ClsA (Latched) — Cont NS ClA Latch: For Class A
latched output modules that output an unsynchronized signal. Does not follow
Signal Silence.
Supervised Outputs ClsA (Latched) — SupOut ClA Latch: For Class A latched
output modules that output an unsynchronized signal. Does not follow Signal
Silence.
Relay Non-Silenceable (Latched) — Relay Latch: For Class B relay devices
functioning as latched output devices. Does not follow signal silence.
Relay Non-Silence NO (Latched) — Relay NO Latch: For relay devices
functioning as latched output devices that close when activated. Does not
follow signal silence.
Relay Non-Silence NC (Latched) — Relay NC Latch: For relay devices
functioning as latched outputs that open when activated. Does not follow
signal silence.
