Chapter 2: Front panel programming
Vigilant VS1 and VS2 Technical Reference Manual 107
5. Press the Menu button to exit menu mode, or
continue programming.
Save
Annunciator programming
Each annunciator on the annunciator loop must be programmed for type, number of
expanders, label, and event notification. Up to eight annunciators can be connected
on the loop and each must be programmed separately.
Table 28: Annunciator options
Option Description
Annunciator type Set annunciator type to:
Off: No annunciator is connected. Note: If type is set to Off, Number
expanders, Label, and Reporting configuration are not available.
LCD-C: The annunciator has a display and common controls
LCD: The annunciator has a display only (no common controls)
LED: The annunciator has LEDs and common controls (no display)
Graphic: Graphics controller interface for the Envoy graphics board
Expanders Set expanders to None, 1, or 2. This is the number of LED expander
modules you are using with the annunciator.
Label Enter a text label for the annunciator (two lines of 20 characters).
When you have finished, choose Save.
Event notification Set the trouble event information by setting the notification
information. When you have finished, choose Save. See “Factory
default settings” on page 35 for annunciator event notification
default settings.
Printer: Yes or No. This controls whether event information is sent to
the printer
Coder: four-digit coded output that is played in response to alarm
conditions (00-00-00-00 to 99-99-99-99)
Dialer:
Acct 1 2: Event information is sent to both dialer accounts
Acct 1: Event information is sent to dialer account one
Acct 2: Event information is sent to dialer account two
None: Event information is not sent to the dialer
NET: Yes or No. Controls whether event information is sent to the
connected network
CID: Contact ID event code (000 to 999)
