Chapter 2: Front panel programming
112 Vigilant VS1 and VS2 Technical Reference Manual
Option Description
Call disconnect seconds Set call disconnect to Off or 1 to 45 seconds. Specifies the length of
time the dialer seizes the line (to disconnect parallel devices) before
attempting to dial out.
Test frequency days Set test frequency to Off or 1 to 45 days. Specifies how often the
dialer performs a test call. Note: The “off” setting is not acceptable
for UL/ULC installations. See “UL 864 programming requirements”
on page 31 for details.
Test time Set the test time to the desired time of day for running the test.
Rings to answer Set rings to answer to Off or 1 to 15 rings. Specifies how many rings
before the dialer answers incoming calls.
Ring type Set ring type to Any or Normal. Specifies the type of ring expected
when an incoming call is received.
Callback Select Enabled or Disabled.
Callback number Enter the callback phone number (up to 20 digits). This specifies the
phone number that is used for call back.
To program the dialer:
1. Display the panel configuration options menu. See
“Panel programming” on page 103.
2. Choose CMS Device.
3. Choose Dialer.
4. Program the dialer using Table 30 on page 110. For
dialer default settings, see “Factory default settings”
on page 35.
5. When you have finished programming each option,
choose Save.
6. Press the Menu button to exit menu mode, or
continue programming.
Panel Configuration
Ann. Class
Annunciator
CMS Device
⇩
CMS Device
Dialer
Network
Swngr Shtdn
Rp.200<>
⇩
Dialer
Type Single Line>
Account 1
Account 2
⇩
CMS Device
Swngr Shtdn
Rp.200<>
Event Notification
Save
CMS network (receiver) programming
The information being programmed here pertains to the central monitoring station
(CMS) network that the control panel uses to communicate with the CMS. This is a
TCP/IP Ethernet network. Event information is sent to the central monitoring station
To Next Page
