Chapter 2: Front panel programming
Vigilant VS1 and VS2 Technical Reference Manual 119
Option Description
Event notification Set event notification to:
Zone: When a device is a member of a zone, only the zone
information is sent to the LCD, LEDs, printer, and dialer. Note:
Device level reporting configuration is not available.
Zone/device: Zone information is sent to the LCD and LEDs. Device
information is sent to the printer and dialer. Note: Zone/device
reporting locations can be configured through custom
programming.
Device: Only device information is reported, no zone information.
LED annunciator operation note: If you are using the optional LED
expanders, the zone LEDs are assigned to device addresses 1 to 32
on loop 1. For example, zone 1 LEDs (red and yellow) are assigned
to device 1 on loop 1.
Remote annunciator operation note: If you are using the optional
remote annunciators, when an event takes place on loop 1, the
loop displays on the annunciator LCD as loop 17 (not loop 1). The
device number of the device reporting the event is the correct
device number. So, if an event takes place on loop 1, the remote
annunciators will display it as loop 17. Loop 2 events will display on
the annunciator LCD as loop 2 events.
Key #1 and Key #2 See “Setting up the programmable keys” on page 51.
To program Panel Operation options:
1. Press the menu button and choose Program.
2. Choose Advanced Program.
3. Enter a level two password.
4. Choose Panel Operation.
5. Program the options using Table 32 on page 118.
Not all options shown in the table will be displayed on
all systems.
6. When you finish programming each option, choose
Save.
7. Press the Menu button to exit menu mode, or
continue programming.
Main Menu
Reports
Test
Control
Program
⇩
Program
Incremental Program
Auto Program
Advanced Program
⇩
Enter Password
0000
Advanced Program
Loop Configuration
Panel Configuration
Panel Operation
⇩
Panel Operation
Language English>
Marketplace US>
AC Fail Delay 15>
To Next Page
