Chapter 2: Front panel programming
Vigilant VS1 and VS2 Technical Reference Manual 125
Unconfigured alarm event programming
The unconfigured alarm event can be assigned to a correlation group and used to
turn on an output device. When it is assigned to a correlation group, every
unconfigured alarm event will turn on every output device in the correlation group.
Event notification can also be programmed for the unconfigured alarm.
To program the unconfigured alarm event:
1. Press the Menu button and choose Programming.
2. Choose Advanced Program and enter the level 2
password.
3. Choose Unconfigured Alarm.
4. Choose Loop 1 Uncfgrd Alarm or Loop 2 Uncfgrd
Alarm. (The second option is displayed only if you
have more than one loop).
5. Choose Correlation Groups and enter the number of
the correlation group.
6. Press Enter to toggle between possible values:
To add the event to the group, choose Included.
— or —
To remove it from the group, choose Excluded.
7. Repeat steps 7 to 9 to add or remove the event from
any remaining correlation groups to be configured.
8. Choose Save.
9. Choose Event Notification.
10. Choose Active.
11. Configure active event notification. (Not all the
options shown here will be displayed on all systems.)
Printer: Controls whether event information is sent to
the printer. Enter toggles between Yes and No.
Coder: Four-digit coded output that is played in
response to alarm conditions (00-00-00-00 to 99-99-
99-99).
Dialer:
Acct 1 & 2: Event information is sent to both dialer
accounts
Advanced Program
Loop Events
Unconfigured Alarms
Common Trouble
⇩
Unconfigured Alarms
Loop 1 Uncfgrd Alarm
Loop 2 Uncfgrd Alarm
⇩
Loop 1 Uncfgrd Alarm
Correlation Groups
Event Notification
⇩
Correlation Groups
Group 001
Status Included
Enter Exit
⇩
Unconfigured Alarm
Correlation Groups
Event Notification
⇩
Event Notification
Active
⇩
Active
Printer Yes<>
Code 10-10-10-10
Dialer Account 1&2
⇩
Active
NET Yes
CID 110
Save
To Next Page
