Appendix B: Worksheets
Vigilant VS1 and VS2 Technical Reference Manual 197
Worksheet A: Control panel current load
Devices Qty
Standby
current (mA)
Alarm
current (mA)
Qty x Standby
current (mA)
Qty x Alarm
current (mA)
Base panel 1 See note [1]
below
See note [2]
below
Primary loop circuit
(fully loaded loop)
55 125
V-SLC loop
expander card (fully
loaded loop)
60 125
SA-CLA Class A card 3 60
SA-232 RS-232 card 13 13
SA-DACT dialer 41 41
SA-ETH network
card
34 34
LED expander 4 1 expander: 48
2 expanders:
96
Totals (mA)
(transfer totals to Battery Calculation Worksheet)
[1] VS1: 155
VS2: 172
[2] VS1: 204
VS2: 267
