Appendix B: Worksheets
198 Vigilant VS1 and VS2 Technical Reference Manual
Worksheet B: Auxiliary/smoke power current load
Devices Qty
Standby
current (mA)
Alarm
current (mA)
Qty x Standby
current (mA)
Qty x Alarm
current (mA)
RPM 20 270
GSA-UM or -MAB [1] 17 58
RLCD(F) 98 113
RLCD-C(F) 99 115
RLED-C(F) 28 62
LED24 6 34
Totals (mA)
(transfer totals to Battery Calculation Worksheet)
[1] Enter 1 regardless of how many are installed. Only the first GSA-UM or -MAB in the alarm state
draws current. The other ones do not because the system load sheds additional modules in
alarm.
