Appendix D: Applications
254 Vigilant VS1 and VS2 Technical Reference Manual
Floor 3 Correlation
Input Output
Floor 3 dwelling and hallway inputs Floor 3 dwelling and hallway audibles
No in suite
signal silence
Floor 4 correlation
Input Output
Floor 4 dwelling and hallway inputs Floor 4 dwelling and hallway audibles
No in suite
signal silence
Floor 5 correlation
Input Output
Floor 5 dwelling and hallway inputs Floor 5 dwelling and hallway audibles
No in suite
signal silence
Creating a hallway correlation
The hallway correlation ensures that an alarm detected anywhere in the building will
turn on all audibles located in hallways throughout the building.
On the input side of this correlation, add all input devices on all floors. Include all
those inside dwelling units and all those in hallways.
On the output side, add all hallway sounders throughout the building.
Notes
• Set the alarm activation count for this correlation to 1.
• Do not enable in-suite signal silence.
Hallway Correlation
Input Output
Occupant and hallway inputs on all floors Hallway sounders on all floors
Creating an in-suite correlation group
The in-suite correlation is used to silence sounders inside dwelling units, except on
the floor of alarm.
Create one in-suite correlation group. On the input side, add all input devices on all
floors. Include those located inside dwelling units and those located in hallways.
On the output side, add all sounders located inside dwelling units on all floors.
Notes
• Set the alarm activation count for this correlation to 1.
• For this correlation only, enable in-suite signal silence.
