Appendix E: Device types to personality codes correlation
Vigilant VS1 and VS2 Technical Reference Manual 259
Model Device type Personality code
CT2 Heat (1) Alarm - NO latching (Class B)
CT2 Monitor (3) Active - NO nonlatching (Class B)
CT2 Pull Station (1) Alarm - NO latching (Class B)
CT2 Remote AC Fail (3) Active - NO nonlatching (Class B)
CT2 Remote Drill (3) Active - NO nonlatching (Class B)
CT2 Remote Reset (3) Active - NO nonlatching (Class B)
CT2 Remote Signal Silence (3) Active - NO nonlatching (Class B)
CT2 Smoke (1) Alarm - NO latching (Class B)
CT2 Supervisory Latching (4) Active - NO latching (Class B)
CT2 Supervisory Nonlatching (3) Active - NO nonlatching (Class B)
CT2 Unlatch outputs (3) Active - NO nonlatching (Class B)
CT2 Water Flow (2) Alarm - NO delayed latching (Class B)
DTS Duct Alarm (1) Alarm - NO latching (Class B)
DTS Duct Supervisory Latching (4) Active - NO latching (Class B)
DTS Duct Supervisory Nonlatching (3) Active - NO nonlatching (Class B)
HFS Heat (1) Alarm - NO latching (Class B)
HRS Heat ROR (1) Alarm - NO latching (Class B)
IM Monitor (1) Alarm - NO latching (Class B)
IO Relay Non-Silence NC (32) Monitor - NO input/output NC
IO Relay Non-Silence NC (Latched) (32) Monitor - NO input/output NC
IO Relay Non-Silence NO (31) Monitor - NO input/output NO
IO Relay Non-Silence NO (Latched) (31) Monitor - NO input/output NO
IO Relay Silence NC (32) Monitor - NO input/output NC
IO Relay Silence NO (31) Monitor - NO input/output NO
IPHS Smoke (1) Alarm - NO latching (Class B)
IPHS Smoke Verified (1) Alarm - NO latching (Class B)
IPHS Supervisory Latching (1) Alarm - NO latching (Class B)
IPHS Supervisory Nonlatching (3) Active - NO nonlatching (Class B)
IS Smoke (1) Alarm - NO latching (Class B)
IS Smoke Verified (1) Alarm - NO latching (Class B)
MAB 2Wire Alarm (13) Alarm - two-wire smoke unverified (Class B)
MAB 2Wire Alarm Class A (20) Alarm - two-wire smoke unverified (Class A)
MAB 2Wire Alarm Verify (14) Alarm - two-wire smoke verified (Class B)
MAB 2Wire Alarm Verify Class A (21) Alarm - two-wire smoke verified (Class A)
