Chapter 2: Front panel programming
80 Vigilant VS1 and VS2 Technical Reference Manual
To add or remove members from a correlation group:
1. Press the Menu button and choose Programming.
2. Choose Advanced Program and enter the level 2
password.
3. Choose Correlation Groups and enter the correlation
group number to be programmed. (Values range
from 001 to 199.)
4. Choose:
Add/Remove Zone to add or remove a zone.
Add/Rem Panel NAC to add or remove a NAC.
Add/Remove Device to add or remove a device.
5. Enter the loop number (if the panel has multiple
loops).
6. Enter the zone, NAC, or device number.
7. On the Status line, press Enter to select Included or
Excluded:
• “Included” adds the item to the group.
• “Excluded” removes the item from the group
8. Repeat steps 4 to 7 to add or remove other devices,
zones, or NACs.
9. Repeat steps 3 to 9 to program additional correlation
groups.
10. Press the Menu button to exit menu mode, or
continue programming.
Loop Configuration
Loop Class
Zone
Correlation Groups
⇩
Correlation Groups
Number 001<>
⇩
Correlation Group 001
Add/Remove Zone
Add/Remove Device
Add/Rem Panel NAC
⇩
Add/Remove Device
Device 001<>
Status Excluded
<-Enter <-Cancel
