page | 112
Basic Operation
Menu System
18. Use the numeric keypad to enter the desired address.
If one or more digits in the address is less then three digits in length, then preceding
zeros must be used to pad the value. For example, if one of the numbers is 10, then
you would enter 010 on the keypad. If the number is 5, then you would enter 005.
The cursor will automatically advance to the next digit in the gateway address.
If an error is made, use the ◄ or ► to move backward or forward between each digit.
19. Press the OK button to save the changes.
gateway:
10.5.64.1
LAN
POE
5V DC
1 2
Matrix Controller
Status
IR
Power
Menu
1 2 3
4 5 6
7 8 9
In 0 Out Set
Clear
Mask
Preset
Back
OK
Lock
gateway:
010.005._01.072
OR
Basic Operation
