Page TitleIntroduction
Getting Started
Getting Started
ID Name Description
14 Back Press this button to return to a previous
screen in the LCM display.
15 Lock Press this button to lock the Matrix
Controller. When the Matrix Controller is
locked, the enter passcode screen will be
shown in the LCM display.
16 OK Press this button to accept the current
entry or setting within the LCM display.
17 LAN 1 (POE) Connect an Ethernet cable from this port
to the LAN. See Combined Mode (page
9) and/or Separate Mode (page 13).
18 LAN 2 Connect an Ethernet cable from this port to a
managed switch. This port is only used if the
video devices are on a separate switch.
See Separate Mode (page 13) for more
information.
19 5V DC Connect the included 5V DC power supply
to this power receptacle. Connect the power
cord to an available electrical outlet.
NOTE: If the LAN 1 port is connected
to a PoE Switch (e.g Netgear ProSafe
GS748TPS), then a separate power
connection is not required.
