Engine Compartment Overview
2.5 T-GDi
OIK013027
The actual engine compartment in the vehicle may differ from the illustration.
(1) Fuse box ................................................................................................................... 9-51
(2) Windshield washer fluid reservoir ..........................................................................9-29
(3) Air cleaner ............................................................................................................... 9-30
(4) Radiator cap ............................................................................................................ 9-27
(5) Engine coolant reservoir ........................................................................................9-25
(6) Liquid-cooled intercooler coolant reservoir.......................................................... 9-27
(7) Engine oil filler cap ..................................................................................................9-22
(8) Engine oil dipstick ...................................................................................................9-22
(9) Brake fluid reservoir ................................................................................................9-28
*Battery is in the trunk
