9
9-31
Cabin Air Filter
Filter inspection
The cabin air filter should be replaced
according to the Maintenance Schedule.
If the vehicle is operated in severely
air-polluted cities or on dusty rough roads
for a long period, it should be inspected
more frequently and replaced sooner.
Replace the cabin air filter by following
the procedure below and be careful to
avoid damaging other components.
Filter replacement
1. Open the glove box and remove the
support rod (1).
OIK093015
2. Remove the stoppers on both sides to
allow the glove box to hang freely on
the hinges.
OIK093016
3. Pull out the cover while Pressing and
holding the lock on the left side of the
cover.
OIK093017
4. Replace the cabin air filter.
5. Reassemble in the reverse order of
disassembly.
OIK093018
Install a new cabin air filter in the correct
direction with the arrow symbol (↓) facing
downwards, to prevent noise and reduce
effectiveness.
0_IK_PE_en_US.book Page 31
