Components of the Tire Mobility Kit
OIK083041
(1) Speed restriction label
(2) Sealant bottle and label with speed restriction
(3) Filling hose
(4) Connectors and cable for the power outlet direct connection
(5) Holder for the sealant bottle
(6) Compressor
(7) ON/OFF switch
(8) Pressure gauge for displaying the tire inflation pressure
(9) Button for reducing the tire inflation pressure
Connectors, cable and connection hose are stored in the compressor housing.
Strictly follow the specified sequence, otherwise the sealant may escape under high
pressure.
WARNING
Expired sealant
Do not use the tire sealant after the sealant has expired (for example, expiration date on
the sealant container). This can increase the risk of tire failure.
