GSi TYMPSTAR Series User Manual

General This chapter describes the system level components and assemblies included in the
TympStar Version 1 and Version 2 instruments.
NOTE
The only hardware difference between
the two versions is the probe assembly.
Hardware components and assemblies are
shown graphically using drawings with part
and assembly number designations.
Assembly drawings The following assembly drawings
are included:
Case/chassis page 6-2
Overall assembly page 6-4
LCD assembly page 6-5
Top case assembly page 6-6
Bottom case assembly page 6-7
Instrument assembly page 6-8
Labels page 6-9
Printer assembly page 6-11
GSI TympStar Version 1 and Version 2 Service Manual 6 - 1
System Level
Parts
6
