GTS iMAPLA series - Spare Parts; GTS Spare Parts List

Page 155 Issue 08/2013
Spare parts
Accessories
12 Spare parts
Companies authorised for repair- and replacement work must get in touch
directly with the manufacturer for the Workshop-/Service manual.
Standard spare parts can be obtained from the manufacturer
or service contact partners under the following list.
GTS spare parts list iMAPLA
SPARE PART GTS iMAPLA 8kW GTS iMAPLA 13kW GTS iMAPLA 17kW
Generator (complete) 0/0100-7477-000-001 0/0100-7677-000-001 0/0100-7877-000-001
Switch box (8-30kW)
without ISO monitoring
0/0101-5232-008-001 0/0101-5232-013-001 0/0101-5233-017-001
Switch box (8-30kW)
with ISO monitoring
0/0101-5232-113-001 0/0101-5233-117-001 0/0101-5235-117-001
MMI (Man-Machine-Interface)
without ISO monitoring
0/0101-9111-408-001 0/0101-9111-413-001 0/0101-9111-417-001
MMI (Man-Machine-Interface)
with ISO monitoring
0/0101-9112-408-001 0/0101-9112-413-001 0/0101-9112-417-001
MMI cable; 10m
straight/angled connector
5/0000-5512-110-001 5/0000-5512-110-001 5/0000-5512-110-001
Load cable (8-30kW
& 20+30m) compl.
withconnector
0/0100-5502-020-001 0/0100-5502-020-001 0/0100-5503-030-001
Joystick cable, 4-pole; 10m;
straight/angled connector
0/0100-5512-110-001 0/0100-5512-110-001 0/0100-5512-110-001
DS3 + DS 6blue socket 0/0100-5880-003-001 0/0100-5880-003-001 0/0100-5880-003-001
DS3 + DS6and connector 0/0100-5881-003-001 0/0100-5881-003-001 0/0100-5881-003-001
MAPLA connector for load
cable
2/1210-5502-020-001 2/1210-5502-020-001 2/1210-5502-020-001
MAPLA connector for
generator
2/1210-5503-002-001 2/1210-5503-002-001 2/1210-5503-002-001
MAPLA load cable socket 2/1210-5501-013-001 2/1210-5501-013-001 2/1210-5501-013-001
Socket on generator 2/1210-7677-013-001 2/1210-7677-013-001 2/1210-7677-013-001
end shield A 3/0004-4022-270-001 3/0004-4022-270-001 3/0004-3020-268-001
B bearing plate 3/0004-3020-244-001 3/0004-3020-244-001 3/0004-4020-671-001
Fan cover 1/0000-5130-211-001 5/0000-5130-210-001 1/0000-5130-211-001
Fan blade 1/0000-5110-011-001 1/0000-5110-013-001 1/0000-5110-042-001
Controller electronics 1/7477-5410-101-001 1/7677-5410-101-001 1/7877-5410-101-001
