GW Instek APS-7000 Series Programming Manual

APS-7000 Programming Manual
104
Note:
The :SOURce:FUNCtion:CSINe:TYPE command
must first be used to set the save slot number
(CLP1|2|3) and SDIP as the waveform type before
this command can be executed.
Syntax
[:SOURce]:FUNCtion:CSINe:SDIP
{CLP1|CLP2|CLP3,<NR1>|SQUare|SINE,<NR2>|MINi
mum|MAXimum,<NR2>|MINimum|MAXimum}
Query Syntax
[:SOURce]:FUNCtion:CSINe:SDIP?
{CLP1|CLP2|CLP3[,MINimum|MAXimum]}
Parameter/Return
parameter
CLP1
Save slot 1
CLP2
Save slot 2
CLP3
Save slot 3
<NR1>|
SQUare|SINE
0 | Square, 1| Sine (Site waveform
shape)
<NR2>
0 ~100%. ACV.
MINimum
0 (0%)
MAXimum
100 (100%)
<NR2>
0 ~100%. Site
MINimum
0 (0%)
MAXimum
100 (100%)
Example
:FUNC:CSIN:SDIP CLP1, SQU,50,50
Sets the surge/dip arbitrary waveform parameters as
site=square, ACV=50%, site=50%.
[:SOURce]:FUNCtion:CSINe:STAircase
Set
Query
Description
Sets or queries the staircase waveform type and the
number of “steps” in the waveform.
Note:
The :SOURce:FUNCtion:CSINe:TYPE command
must first be used to set the save slot number
(CLP1|2|3) and the waveform type (STAircase)
before this command can be executed.
Syntax
[:SOURce]:FUNCtion:CSINe:STAircase
{CLP1|CLP2|CLP3,<NR2>|MINimum|MAXimum}
Query Syntax
[:SOURce]:FUNCtion:CSINe:STAircase?
{CLP1|CLP2|CLP3[,MINimum|MAXimum]}
