GW Instek APS-7000 Series Programming Manual

REMOTE CONTROL
87
:SYSTem:CONFigure:TRIGger:OUTPut
:SOURce
Set
Query
Description
Configures the source for the trigger output.
Equivalent to the Output Pin>Source settings
when Shift + 2[Trigger] is pressed using the front
panel controls.
Syntax
Query Syntax
:SYSTem:CONFigure:TRIGger:OUTPut:SOURce
{<NR1>|NONE|OUTPut|SETTing|PRESet|ZERO-cross|
ALL}
:SYSTem:CONFigure:TRIGger:OUTPut:SOURce?
Parameter
0 | NONE
No source is assigned.
1 | OUTPut
Turning the output on will generate a
trigger.
2 | SETTing
Changing a setting will generate a
trigger.
3 | PRESet
Loading a preset will generate a trigger.
4 | ZERO-cross
When the output waveform at zero cross
will generate a trigger.
5 |ALL
The output source is any of the above
actions.
Return parameter
+0
No source is assigned.
+1
Turning the output on will generate a
trigger.
+2
Changing a setting will generate a
trigger.
+3
Loading a preset will generate a trigger.
+4
When the output waveform at zero cross
will generate a trigger.
+5
The output source is any of the above
actions.
Example
:SYST:CONF:TRIG:OUTP:SOUR?
>0
No trigger source is assigned.
