GW Instek APS-7000 Series Programming Manual

APS-7000 Programming Manual
108
Syntax
[:SOURce]:SEQuence:CPARameter
{<NR2>,<NR2>,<bool>|OFF|ON,<NR2>,<bool>|OFF|
ON,<NR1>|CONTinue|END|HOLD,<NR1>,<bool>|OF
F|ON,<NR1>,<bool>|OFF|ON,<NR1>,<bool>|OFF|O
N,<NR1>,<bool>|OFF|ON,<bool>|OFF|ON}
Query Syntax
[:SOURce]:SEQuence:CPARameter?
Parameter
<NR2>
Step Time
<NR2>
On phase
<bool>|OFF|ON
On phase on(1)/off(0)
<NR2>
Off phase
<bool>|OFF|ON
Off phase on/off
<NR1>|CONTinue|
END|HOLD
Term settings:
Continue(1)/End(2)/Hold(3)
<NR1>
Jump step number (0 ~ 255)
<bool>|OFF|ON
Jump on(1)/off(0)
<NR1>
<bool>|OFF|ON
Jump Cnt (0~ 255)
Code (External trigger output):
ON=1/OFF=0
<NR1>
Branch1 (0 ~ 255)
<bool>|OFF|ON
Branch1 on(1)/off(0)
<NR1>
Branch2 (0 ~ 255)
<bool>|OFF|ON
Branch2 on(1)/off(0)
<bool>|OFF|ON
Trig Out. HI=1/LO=0
Return parameter
<NR2>,<NR2>,<bool>,<NR2>,<bool>,<NR1>,<NR1>,
<bool>,<NR1>,<bool>,<NR1>,<bool>,<NR1>,<bool>,
<bool>
Returns the common parameters in the following order:
Step time, on phase, on phase on/off, off phase, off
phase on/off, term settings, jump step number, jump
on/off, jump count, code on/off, branch1, branch1
on/off, branch2, branch2 on/off, trig out on/off.
Example1
:SEQ:CPAR 1,0,10,1,HOLD,10,1,0,1,0,0,0,0,1
Example2
:SEQ:CPAR?
>+0.1000,+0,+0,+0,+0,CONT,+1,+1,+1,+0,+0,+0,+0,+0,
+0
[:SOURce]:SEQuence:CSTep
Query
Description
Returns the currently running step number.
