APS-7000 Programming Manual
136
Output OFF after RMS current
limiter is activated
11
2048
RMS current limiter is operating
13
8192
Always 0
15
32768
Condition
Register
The Warning Status Condition Register indicates
the warning status of the power supply. If a bit is
set in the Condition register, it indicates that the
event is true. Reading the condition register does
not change the state of the condition register.
PTR/NTR Filters
The PTR/NTR (Positive/Negative transition)
register determines the type of transition
conditions that will set the corresponding bit in the
Event Registers. Use the Positive transition filter to
view events that change from false to positive, and
use the negative transition filter to view events
that change from positive to negative.
Positive Transition
01
Negative Transition
10
Event Register
The PTR/NTR Register will dictate the type of
transition conditions will set the corresponding
bits in the Event Register. If the Event Register is
read, it will be cleared to 0.
Enable Register
The Enable register determines which registered
Events in the Event Register will be used to set the
WAR bit in the Status Byte Register.
