GW Instek APS-7000 Series Programming Manual

REMOTE CONTROL
25
Note
The RS-232/USB (APS-002) or RS-232 (APS-007) must
first be installed before the RS-232 interface can be
used for remote control. Please see the user manual
for installation details.
Steps
1. Connect the RS-232C cable from
the PC to the rear panel RS-232
port.
2. Press the Menu key. The Menu
setting will appear on the display.
Menu
3. Use the scroll wheel to go to item 7, Serial Port
and press Enter.
4. Go to the Function Active setting and turn the
serial port connection on.
Function Active
ON, OFF
5. Set the remaining serial port settings.
Baud rate
1200, 2400, 4800,
9600(default), 19200, 38400,
57600, 115200,
Data bits
7, 8(default)
Parity
None(default), odd, even
Stop bits
1(default),2
Serial port configuration
