Hasselblad X1D II 50C User Manual

X1D II 50C USER GUIDE www.hasselblad.com
INTRODUCTION
Contents
14
1.10 BATTERY
Rechargeable Battery
The environmentally approved Battery is the standard Power
Source for the X1D II Camera (1). It is advisable to keep an
extra fully recharged battery on hand. As is the case with
most batteries, problems might be encountered when used in
very low temperatures. In this situation it is advisable to keep
the reserve battery inside a warm pocket, for example, to
maintain it near body temperature.
How to remove a Battery
1 Remove the Battery (1) from the camera by rotating the
Battery Lever (2) .
2 The Battery will move up a bit (3) automatically.
3 Then press the Battery in a bit but not all the way, to
release it from the Camera completely.
4 Remove the battery (4) .
How to mount a Battery
1 Align the battery so the contacts are facing the lens and
push it into the Camera Battery Compartment until it locks
into place.
Note!
When the battery is inserted, the rear Status LED will show a
blink sequence once to indicate the current battery charge
level. See next page for details.
1
2
3
4

Hasselblad X1D II 50C Specifications

General

Megapixel	50 MP
Camera type	MILC Body
Sensor type	CMOS
Image sensor size	- \
Image formats supported	JPEG, RAW
Maximum image resolution	8272 x 6200 pixels
Image sensor size (W x H)	43.8 x 32.9 mm
Still image resolution(s)	-
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-C
Headphone outputs	1
Optical zoom	- x
Shooting modes	Auto, Manual
Self-timer delay	- s
Product color	Black
Battery voltage	7.27 V
Battery capacity	3400 mAh
Battery recharge time	2 h
Magnification	0.87 x
Viewfinder type	Electronic
Viewfinder resolution	3690000 pixels
Display diagonal	3.6 \
Display resolution (numeric)	2360000 pixels
Memory slots	2
Compatible memory cards	SD
Operating temperature (T-T)	-10 - 45 °C
Maximum video resolution	- pixels
Flash range (wide)	- m
Fastest camera shutter speed	1/10000 s
Slowest camera shutter speed	4080 s
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Auto
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Focus adjustment	Auto/Manual

Weight and Dimensions

Depth	70 mm
Width	148 mm
Height	97 mm
Weight	650 g
Weight (including battery)	766 g
