Hasselblad X1D II 50C User Manual

1 AF/MF button
The AF/MF button toggles between Autofocus and Manual
Focus.
Can be reprogrammed as described on page 112.
2 ISO/WB button
This button provides direct access to the ISO and WB
settings. Press one time to change ISO settings. Press
again to change WB settings.
Can be reprogrammed as described on page 112.
3 Front Scroll Wheel
The front and Rear Scroll Wheels are used to make
changes in exposure settings, navigate the Touch Display
Menu as well as acting as browse controls.
4 Shutter Release Button
This button has two positions. Press half way (or soft) to
activate the camera, auto focus function and exposure
meter. Press all the way down (or more rm) to release the
shutter. The chosen exposure procedure and the self timer
are also activated with this button.
5 Mode Dial
Select any of the 10 programs. MQ, M, A, S, P , Full
Automatic mode, Video mode and 3 Custom modes C3,
C2 and C1.
6 ON / OFF button
Press the button for 1 second to turn on the camera.
The X1D II start up logo will appear and then the Control
Screen. After a few seconds (customizable) of inactivity the
camera will enter Display Off mode. A long press on the
button turns the camera off completely (even from Display
Off mode). A short press on the button toggles Touch
Display On and Off.
7 Rear Scroll Wheel
The scroll wheel is used to make changes in exposure
settings, to navigate the Camera menus as well as acting
as browse control.
Note!
Video mode will be implemented in a coming rmware
release.
Note!
Some of the buttons have multiple functions according to the
settings made.
Note!
Some of the buttons can be reprogrammed to a different
function. See page 112.
Note!
In addition to the release button, the X1D II camera can also
be remotely released using the X System Release Cable. See
page 63 and page 137.
4.2 GRIP BUTTONS AND CONTROLS
5
6
7
3
4
1
2
X1D II 50C USER GUIDE www.hasselblad.com
35
FUNCTIONS
Contents

Hasselblad X1D II 50C Specifications

General

Megapixel	50 MP
Camera type	MILC Body
Sensor type	CMOS
Image sensor size	- \
Image formats supported	JPEG, RAW
Maximum image resolution	8272 x 6200 pixels
Image sensor size (W x H)	43.8 x 32.9 mm
Still image resolution(s)	-
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-C
Headphone outputs	1
Optical zoom	- x
Shooting modes	Auto, Manual
Self-timer delay	- s
Product color	Black
Battery voltage	7.27 V
Battery capacity	3400 mAh
Battery recharge time	2 h
Magnification	0.87 x
Viewfinder type	Electronic
Viewfinder resolution	3690000 pixels
Display diagonal	3.6 \
Display resolution (numeric)	2360000 pixels
Memory slots	2
Compatible memory cards	SD
Operating temperature (T-T)	-10 - 45 °C
Maximum video resolution	- pixels
Flash range (wide)	- m
Fastest camera shutter speed	1/10000 s
Slowest camera shutter speed	4080 s
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Auto
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Focus adjustment	Auto/Manual

Weight and Dimensions

Depth	70 mm
Width	148 mm
Height	97 mm
Weight	650 g
Weight (including battery)	766 g
