3.2 REMOVE AND ATTACH A LENS
REMOVE THE LENS
Caution!
Be careful when you attach/remove the components to/from
the camera. This will help prevent damage to the data bus
connections.
Caution!
Do not insert ngers into the camera body. This can cause
damage to the equipment.
1 Hold the lens
(C)
with one hand and hold the camera body
(A)
still.
2 Push the lens removal button
(B)
.
3 Rotate the lens counter clockwise.
4 Push the lens
(C)
away from the camera body.
5 Attach the protection cover
(D)
on the camera body
directly.
6 Attach the lens protection caps on the detached lens to
prevent damage.
7 Store the lens with both lens protection caps on and the
lens hood inverted over the lens instead of in front of the
lens
(E)
.
A
B
C
D
E
X1D II 50C USER GUIDE www.hasselblad.com
24
