PREVIEW OVERLAYS
In addition to the Standard overlay as described on page
82, the available overlays are: Histogram Mode, Capture
Details Mode, Luminance Histogram Mode and Separate
Histogram RGB Mode.
HISTOGRAM MODE
Histogram mode displays RGB Histogram with separate RGB
channels visible. The RGB details are stored with the capture
le, and can be referred to in Phocus and other applications.
CAPTURE DETAILS MODE
The Capture Details Mode displays SD Card (1), Date (19-05-
19), Time (14:32:08), selected Aperture (f/11), Shutter Speed
(250), ISO (100), EV Settings (+/- 0.0), Mode (A), Light Meter
Mode (Center Weighted), White Balance (Daylight), Focal
Length (45mm).
HOW TO CHANGE HISTOGRAM OVERLAY
Tap the lower part of the image or use the rear scroll wheel or
Rectangle Button to alter between the available Histogram
representations.
LUMINANCE HISTOGRAM MODE
The Luminance Histogram mode displays the luminosity. The
luminance is represented by a White Graph.
SEPARATE HISTOGRAM RBG MODE
In Separate Histogram RGB Mode, the individual RBG
channels are displayed. The Red R channel rst, the Green G
channel in the middle and the Blue B channel below the Red
and Green channels.
X1D II 50C USER GUIDE www.hasselblad.com
86
