X1D II 50C USER GUIDE www.hasselblad.com
93
SETTINGS
Contents
TRUE EXPOSURE EXPLAINED
True Exposure is an XCD and HC/HCD lens function that
allows the shutter speed to remain unaffected when stopping
down. This effect is perhaps not so commonly understood as
it is restricted specically to integral lens shutters as opposed
to focal plane shutters.
When a lens is stopped down, the effective shutter speed
becomes longer, consequently affecting the set exposure. At
slow shutter speeds the effect is minimal but at faster speeds,
e.g. 1/500s, the effect becomes clearly visible. Automatic
compensatory measures in speed setting adjustments are
employed.
As compensation can only be put into effect where speeds
can be adjusted, this prevents the possibility of adjusting the
fastest speed. To counter this, compensatory adjustments
are therefore made to the aperture instead to retain the set
exposure. This compensation is not always required and when
using ash/strobe as the main light source it is actually unde-
sirable because compensation will result in underexposure.
Therefore, when using ash/strobe as the main light source,
you should set True Exposure to OFF in Main Menu > Camera
Settings > Exposure > True Exposure in the Camera Display.
You can download a complete explanation of this situation
from www.hasselblad.com.
Time
Light level at
image plane
Maximum aperture
Stopped down one stop
with True Exposure ON
Stopped down one stop
with True Exposure OFF
T fully open
T stopped down = T Fully open
T stopped down > T Fully open
(Using True Exposure)
(Without True Exposure)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hasselblad X1D II 50C and is the answer not in the manual?

Hasselblad X1D II 50C Specifications

General IconGeneral
Megapixel50 MP
Camera typeMILC Body
Sensor typeCMOS
Image sensor size- \
Image formats supportedJPEG, RAW
Maximum image resolution8272 x 6200 pixels
Image sensor size (W x H)43.8 x 32.9 mm
Still image resolution(s)-
Wi-FiYes
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
USB version3.2 Gen 1 (3.1 Gen 1)
USB connectorUSB Type-C
Headphone outputs1
Optical zoom- x
Shooting modesAuto, Manual
Self-timer delay- s
Product colorBlack
Battery voltage7.27 V
Battery capacity3400 mAh
Battery recharge time2 h
Magnification0.87 x
Viewfinder typeElectronic
Viewfinder resolution3690000 pixels
Display diagonal3.6 \
Display resolution (numeric)2360000 pixels
Memory slots2
Compatible memory cardsSD
Operating temperature (T-T)-10 - 45 °C
Maximum video resolution- pixels
Flash range (wide)- m
Fastest camera shutter speed1/10000 s
Slowest camera shutter speed4080 s
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAuto
ISO sensitivity (max)25600
ISO sensitivity (min)100
Focus adjustmentAuto/Manual
Weight and Dimensions IconWeight and Dimensions
Depth70 mm
Width148 mm
Height97 mm
Weight650 g
Weight (including battery)766 g
