Modules and transducers
110 A03031_24_E00_01 HBM: public QuantumX
Red Error
Connection LEDs
All LEDs are orange Boot procedure running (system is not ready)
All LEDs are flashing
orange
Firmware download active (system is not ready)
Orange Connection newly assigned, transducer identification running
(calibration)
Green Error-free operation
Flashing green (5s),
then green
TEDS data being read in
Flashing orange (5 s),
then green
Manual configuration ongoing (ignore TEDS)
Red Amplifier overload, no sensor connected
Channel error (incorrectly parameterized, connection error,
invalid TEDS data)
Flashing red Sensor supply overload
General rule: Brief flashing → TEDS identified (green: is used, orange: is not used).
