Transducer connection
132 A03031_24_E00_01 HBM: public QuantumX
9.14 DC voltage sources 60 V
The following amplifiers support a measuring range of
"60 V: MX840B, MX440B, MX1601B
Pin assignments for MX1601B see section 8.10.1
9
4
Hsg.
14
(-)
(+)
U
Cable shield
Hsg. = Housing
6
1
123
1-wire EEPROM (optional)
view from below
1
5
6
10
11
15
2 Data
3 No function
1
1
5
2
8
4
MX1601B
Maximum input voltage to housing and
supply ground:
MX840B, MX440B, MX1601B: "60 V
MX1601B: ±40 V
MX1615B: ±15 V
Sensor supply: 5 V … 24 V:
0 V:
Pin 12
Pin 11
Pin 6
Pin 7
1
8
Push in
MX840B and MX440B:
You can select two measuring ranges (10 V or 60 V), depending on the param
eterization.
