Accessories
178 A03031_24_E00_01 HBM: public QuantumX
Order no.DescriptionArticle
D-Sub-HD 15‐pin
Resistive quarter
bridge adapter
SG quarter bridge adapter (SCMSG120
with 120 ohm completion resistor, or
SCMSG350 with 350 ohm completion
resistor, or SCMSG1000 with 1000 ohm
completion resistor).
Signal conditioning SG quarter bridge on
QuantumX input with full bridge. Integ
rated 120-ohm (350-ohm, 1000‐ohm)
completion resistor for quarter bridge,
shunt calibration, TEDS, D-Sub-HD
device connection, Solder joints for trans
ducer lead in a 3wire configuration.
1-SCM-SG120
1-SCM-SG350
1-SCM-SG1000
DSubHD 15‐pin to
adapter BNC
BNCsockettoDSubHD15pinplug
adapter for connection of currentfed, pie
zoelectric sensors (IEPE) or voltage
(±10 V) with BNC to MX410B, MX840B or
MX440B (length approx. 5 cm).
1-SUBHD15-BNC
Adapter D-Sub-HD
15‐pin to D-Sub
15‐pin
Adapter D-Sub-HD 15-pin to D-Sub
15-pin for connecting transducers with
pre-assembled D-Sub plugs on MX840
(length approx. 0.3 m).
Note: Ready-made for full-bridge (6-wire).
1-KAB416
PushIn connector (8
Pins), Gold
10 push-in-connectors, Phönix Contact, 8
Pins, Gold, (Module: MX1601B,
MX1615B, MX879B).
Note: Do not connect these gold plugs to
MX1601 or MX615 devices (risk of corro
sion!).
1-CON-S1015
1-wire EEPROM
DS24B33
Package consisting of 10 units 1-wire
EEPROM DS24B33 (for TEDS as per
IEEE 1451.4.).
1-TEDS-PAK
