Operator control/settings
WTX110 A4774-1.0 HBM: public 57
DescriptionDisplayMeaning
Scale interval e /
division d
For example:
e=d=0.1 g
Legal for trade scale division – scale
division e and display increment
scale interval d (in most cases e is the
same as d)
12:14 PM Time display
Information
The electronic typeplate is hidden with the setting in 'Service
Mode\Calibration\Adaptation\Onscreen typeplate=N' or for certain types of
scales (which ones?).
Weight indicator
Meaning Display Description
Scale no. W1 Scale no. selected with the scale toggle
key
Weighing range no. W1.1 … W1.3 Partial weighing range for multi-range
weighing machines
Scale standstill
symbol
Weight stabilized (printing/saving
possible)
Zero symbol >0< Scale is stopped in gross zero range
(±0.2 d)
Tare 7.9 g T Display of tare weight
Gross weight or net
weight
For example 1250
For example
1000.0 g Net
Switch between legal for trade gross
weight / net weight with Tare key
Net display symbol Net Scale is tared
Unit For example g Weight unit, adjustable in calibration
mode
