HEIDENHAIN iTNC 530 147

4.1 Adding Comments

Functions for editing of the comment

Function Soft key

Jump to beginning of comment.

Jump to end of comment.

Jump to the beginning of a word. Words must be

separated by a space.

Jump to the end of a word. Words must be

separated by a space.

Switch between insert mode and overwrite

mode.
