596 Test Run and Program Run

16.2 Functions for Program Display

Overview

In the program run modes of operation as well as in the Test Run

mode, the TNC provides the following soft keys for displaying a part

program in pages:

Functions Soft key

Go back in the program by one screen

Go forward in the program by one screen

Go to the beginning of the program

Go to the end of the program
