6.4 Path Contours—Cartesian Coordinates
6.4 Path Contours—Cartesian
Coordinates
Overview of path functions
Function Path function key Tool movement Required input Page
Line L Straight line Coordinates of the end
points of the straight line
Page 218
Chamfer CHF Chamfer between two
straight lines
Chamfer side length Page 219
Circle Center CC None Coordinates of the circle
center or pole
Page 221
Circle C Circular arc around a circle
center CC to an arc end
point
Coordinates of the arc end
point, direction of rotation
Page 222
Circular arc CR Circular arc with a certain
radius
Coordinates of the arc end
point, arc radius, direction
of rotation
Page 223
Circular arc CT Circular arc with tangential
connection to the
preceding and subsequent
contour elements
Coordinates of the arc end
point
Page 225
Corner Rounding RND Circular arc with tangential
connection to the
preceding and subsequent
contour elements
Rounding radius R Page 220
FK Free Contour
Programming
Straight line or circular path
with any connection to the
preceding contour element
see "Path Contours—FK
Free Contour
Programming", page 238
Page 242
