396 Programming: Special Functions

11.3 Fixture Monitoring (Software Option)

Manage fixtures

You can save and restore measured fixtures via the Archive function.

This function is especially useful for integrated fixtures and speeds up

the setup procedure considerably.

Manage fixtures

The following functions for fixture management are available:

Function Soft key

Save fixture

Load saved fixture

Copy saved fixture

Rename saved fixture

Delete saved fixture
