HEIDENHAIN iTNC 530 381

11.1 Overview of Special Functions

Program defaults menu

U Select the program defaults menu

Functions for contour and point machining

U Select the menu for functions for contour and point

machining.

Function Soft key Description

Define the workpiece blank Page 107

Define the material Page 436

Define global cycle parameters See User’s

Manual for Cycles

Select datum table See User’s

Manual for Cycles

Function Soft key Description

Assign contour description See User’s

Manual for Cycles

Define a simple contour formula See User’s

Manual for Cycles

Select a contour definition See User’s

Manual for Cycles

Define a complex contour

formula

See User’s

Manual for Cycles

Define regular machining pattern See User’s

Manual for Cycles

Select the point file with

machining positions

See User’s

Manual for Cycles
