HEIDENHAIN iTNC 530 373
10.4 Miscellaneous Functions for Contouring Behavior
Suppressing touch probe monitoring: M141
Standard behavior
When the stylus is deflected, the TNC outputs an error message as
soon as you attempt to move a machine axis.
Behavior with M141
The TNC moves the machine axes even if the touch probe is
deflected. This function is required if you wish to write your own
measuring cycle in connection with measuring cycle 3 in order to
retract the stylus by means of a positioning block after it has been
deflected.
Effect
M141 is effective only in the block in which it is programmed.
M141 becomes effective at the start of the block.
Danger of collision!
When dynamic collision monitoring (DCM) is active, the
TNC might move the tool only until it detects a collision
and, from there, complete the NC program without any
error message. This can result in tool paths different from
those programmed!
Danger of collision!
If you use M141, make sure that you retract the touch
probe in the correct direction.
M141 functions only for movements with straight-line
blocks.
