472 Programming: Multiple Axis Machining
12.3 Inclined-Tool Machining in the Tilted Plane
Inclined-tool machining via normal vectors
U Retract the tool
U Activate M128
U Define any PLANE function; consider the positioning behavior
U Execute program with LN block in which the tool direction is defined
by a vector
Example NC blocks:
Only one directional vector can be defined in the LN block.
This vector defines the incline angle (normal vector NX, NY,
NZ, or tool direction vector TX, TY, TZ).
...
12 L Z+50 R0 FMAX M128
Position at clearance height, activate M128
13 PLANE SPATIAL SPA+0 SPB+45 SPC+0 MOVE SETUP50 F1000
Define and activate the PLANE function
14 LN X+31.737 Y+21.954 Z+33.165 NX+0.3 NY+0 NZ+0.9539 F
1000 M3
Set the incline angle with the normal vector
...
Define machining in the tilted working plane
