Miscellaneous functions
M Effect Effective at block... Start End Page
M0 Program run STOP/Spindle STOP/Coolant OFF Page 357
M1 Optional program STOP/Spindle STOP/Coolant OFF (machine-dependent) Page 615
M2 Program run STOP/Spindle STOP/Coolant OFF/Clear status display
(depending on machine parameter)/Go to block 1
Page 357
M3
M4
M5
Spindle ON clockwise
Spindle ON counterclockwise
Spindle STOP
Page 357
M6 Tool change/Stop program run (depending on machine parameter)/Spindle STOP Page 357
M8
M9
Coolant ON
Coolant OFF
Page 357
M13
M14
Spindle ON clockwise/Coolant ON
Spindle ON counterclockwise/Coolant ON
Page 357
M30 Same function as M2 Page 357
M89 Vacant miscellaneous function or
Cycle call, modally effective (depending on machine parameter)
Cycles
Manual
M90 Only in lag mode: Constant contouring speed at corners Page 361
M91 Within the positioning block: Coordinates are referenced to machine datum Page 358
M92 Within the positioning block: Coordinates are referenced to position defined by machine
tool builder, such as tool change position
Page 358
M94 Reduce the rotary axis display to a value below 360° Page 480
M97 Machine small contour steps Page 363
M98 Machine open contours completely Page 365
M99 Blockwise cycle call Cycles
Manual
M101
M102
Automatic tool change with replacement tool if maximum tool life has expired
Reset M101
Page 188
M103 Reduce feed rate during plunging to factor F (percentage) Page 366
M104 Reactivate the datum as last defined Page 360
M105
M106
Machining with second k
v
factor
Machining with first k
v
factor
Page 660
M107
M108
Suppress error message for replacement tools with oversize
Reset M107
Page 188
