HEIDENHAIN iTNC 530 423
11.7 Generate a Backward Program
11.7 Generate a Backward Program
Function
With this TNC function you can reverse the machining direction of a
contour.
U Select the program whose machining direction you
want to reverse.
U Press the Special Functions key.
U Press the Programming Aids soft key.
U Select the soft-key row with functions for converting
programs.
U Generate a forward and backward program.
Note that the TNC may need many times more free
memory space on the hard disk than the size of the
program file to be converted.
The name of the file created by the TNC consists of the
old file name and the extension _rev. Example:
îš„ File name of the program whose machining direction is
to be reversed: CONT1.H
îš„ File name of the backward program to be generated by
the TNC: CONT1_rev.h
To be able to generate a backward program, the TNC
must first generate a linearized forward program, i.e. a
program in which all contour elements are resolved. This
program is also executable and has the file name
extension _fwd.h.
