648 MOD Functions

17.14 Entering the Axis Traverse Limits, Datum Display

Datum display

The values shown at the top right of the screen define the currently

active datum. The datum can have been set manually or can have been

activated from the preset table. The datum cannot be changed in the

screen menu.

The displayed values depend on your machine

configuration. Refer to the notes in Chapter 2 (see

“Explanation of values saved in the preset table” on page

546).
