676 Tables and Overviews
18.2 Pin Layouts and Connecting Cables for the Data Interfaces
When using the 9-pin adapter block:
Non-HEIDENHAIN devices
The connector layout of a non-HEIDENHAIN device may substantially
differ from the connector layout of a HEIDENHAIN device.
It depends on the unit and the type of data transfer. The table below
shows the connector pin layout on the adapter block.
TNC Connecting cable 355 484-xx
Adapter block
363 987-02
Connecting cable 366 964-xx
Male Assignment Female Color Male Female Male Female Color Female
1 Do not assign 1 Red 1 1 1 1 Red 1
2 RXD 2 Yellow 2 2 2 2 Yellow 3
3TXD 3 White 3 3 33 White 2
4 DTR 4 Brown 4 4 4 4 Brown 6
5 Signal GND 5 Black 5 5 5 5 Black 5
6 DSR 6 Violet 6 6 6 6 Violet 4
7RTS 7 Gray 7 7 77 Gray 8
8 CTS 8 White/Green 8 8 8 8 White/Green 7
9 Do not assign 9 Green 9 9 9 9 Green 9
Hsg. Ext. shield Hsg. Ext. shield Hsg. Hsg. Hsg. Hsg. Ext. shield Hsg.
Adapter block 363 987-02 Connecting cable 366 964-xx
Female Male Female Color Female
111Red1
2 2 2 Yellow 3
333White2
4 4 4 Brown 6
5 5 5 Black 5
6 6 6 Violet 4
777Gray8
8 8 8 White/Green 7
999Green9
Hsg. Hsg. Hsg. Ext. shield Hsg.
