HEIDENHAIN ITNC 530 - CONVERSATIONAL PROGRAMMING User Manual

HEIDENHAIN iTNC 530 553
14.5 Using the 3-D Touch Probe
Storing measured values in the pallet preset
table
U Select any probe function
U Enter the desired coordinates of the datum in the appropriate input
boxes (depends on the touch probe cycle being run)
U Enter the preset number in the Number in table: input box
U Press the ENTER IN PALLET PRES. TAB. soft key. The TNC saves
the datum in the preset table under the number entered
You use this function for determining pallet datums. This
function must be enabled by your machine tool builder.
In order to store a measured value in the pallet preset
table, you must activate a zero preset before probing. A
zero preset consists of the entry 0 in all axes of the preset
table!
