192 Programming: Tools
5.2 Tool Data
There are two ways to run a tool usage test for a pallet file:
îš„ The highlight is on a pallet entry in the pallet file:
The TNC runs the tool usage test for the entire pallet.
îš„ The highlight is on a program entry in the pallet file:
The TNC runs the tool usage test for the selected program.
BLOCK Block number in which the TOOL CALL block
was programmed
PATH îš„ TOKEN = TOOL: Path name of the active main
program or subprogram
îš„ TOKEN = STOTAL: Path name of the
subprogram
T Tool number with tool index
OVRMAX Maximum feed rate override that occurred
during machining. During test run, the TNC
enters the value 100 (%)
OVRMIN Minimum feed rate override that occurred
during machining. During test run, the TNC
enters the value -1
NAMEPROG îš„ 0: The tool number is programmed
îš„ 1: The tool name is programmed
Column Meaning
