Changed functions 340 49x-06
HEIDENHAIN iTNC 530 27
Changed functions 340 49x-06
Q parameter programming: In the FN20 function WAIT FOR you can
now enter 128 characters (see “FN 20: WAIT FOR: NC and PLC
synchronization” on page 324).
In the calibration menus for touch probe length and radius, the
number and name of the active tool are also displayed now (if the
calibration data from the tool table are to be used, MP7411 = 1, see
"Managing more than one block of calibrating data", page 556).
During tilting in the Distance-To-Go mode, the PLANE function now
shows the angle actually left to be traversed until the target position
(see “Position display” on page 451).
The approach behavior during side finishing with Cycle 24 (DIN/ISO:
G124) was changed (see User's Manual for Cycle Programming).
