HEIDENHAIN iTNC 530 287
8.6 Programming Examples
7 LBL 1 Set label for program section repeat
8 L IZ-4 R0 FMAX Infeed depth in incremental values (in space)
9 APPR CT X+2 Y+30 CCA90 R+5 RL F250 Contour approach
10 FC DR- R18 CLSD+ CCX+20 CCY+30 Contour
11 FLT
12 FCT DR- R15 CCX+50 CCY+75
13 FLT
14 FCT DR- R15 CCX+75 CCY+20
15 FLT
16 FCT DR- R18 CLSD- CCX+20 CCY+30
17 DEP CT CCA90 R+5 F1000 Contour departure
18 L X-20 Y+0 R0 FMAX Retract tool
19 CALL LBL 1 REP 4 Return jump to LBL 1; section is repeated a total of 4 times
20 L Z+250 R0 FMAX M2 Retract in the tool axis, end program
21 END PGM PGMWDH MM
