HEIDENHAIN iTNC 530 307

9.8 Additional Functions

Overview

Press the DIVERSE FUNCTION soft key to call the additional

functions. The TNC then displays the following soft keys:

Function Soft key Page

FN 14:ERROR

Output of error messages

Page 308

FN 15:PRINT

Unformatted output of texts or

Q parameter values

Page 312

FN 16:F-PRINT

Formatted output of texts or Q parameter

values

Page 313

FN 18: SYS-DATUM READ

Read system data

Page 317

FN 19:PLC

Send values to the PLC

Page 323

FN 20:WAIT FOR

Synchronize NC and PLC

Page 324

FN 25:PRESET

Set the datum during program run

Page 326

FN 26:TABOPEN

Open a freely definable table

Page 444

FN 27:TABWRITE

Write to a freely definable table

Page 444

FN 28:TABREAD

Read from a freely definable table

Page 445
