HEIDENHAIN iTNC 530 309

9.8 Additional Functions

1016 Contradictory input

1017 CYCL incomplete

1018 Plane wrongly defined

1019 Wrong axis programmed

1020 Wrong rpm

1021 Radius comp. undefined

1022 Rounding-off undefined

1023 Rounding radius too large

1024 Program start undefined

1025 Excessive nesting

1026 Angle reference missing

1027 No fixed cycle defined

1028 Slot width too small

1029 Pocket too small

1030 Q202 not defined

1031 Q205 not defined

1032 Q218 must be greater than Q219

1033 CYCL 210 not permitted

1034 CYCL 211 not permitted

1035 Q220 too large

1036 Q222 must be greater than Q223

1037 Q244 must be greater than 0

1038 Q245 must not equal Q246

1039 Angle range must be < 360°

1040 Q223 must be greater than Q222

1041 Q214: 0 not permitted

Error number Text
