322 Programming: Q Parameters
9.8 Additional Functions
9 W axis
Status of M128, 280 1 - 0: M128 inactive, value not equal to 0: M128 active
2 - Feed rate that was programmed with M128
Status of M116, 310 116 - 0: M116 inactive, value not equal to 0: M116 active
128 - 0: M128 inactive, value not equal to 0: M128 active
144 - 0: M144 inactive, value not equal to 0: M144 active
Current system time of the TNC,
320
1 0 System time in seconds that have elapsed since 00:00
of January 1, 1970
TS triggering touch probe, 350 10 - Touch probe axis
11 - Effective ball radius
12 - Effective length
13 - Radius setting ring
14 1 Center offset (reference axis)
2 Center offset (minor axis)
15 - Direction of center misalignment compared with 0°
position
TT tool touch probe 20 1 Center point X axis (REF system)
2 Center point Y axis (REF system)
3 Center point Z axis (REF system)
21 - Probe contact radius
Last touch point in TCH PROBE
Cycle 0 or last touch point from
manual operating mode, 360
1 1 to 9 Position in the active coordinate system in axes 1 to 9
2 1 to 9 Position in the REF system in axes 1 to 9
Value from the active datum
table in the active coordinate
system, 500
Datum
number
1 to 9 X axis to W axis
REF value from the active datum
table, 501
Datum
number
1 to 9 X axis to W axis
Read value from the preset
table, considering the machine
kinematics, 502
Preset
number
1 to 9 X axis to W axis
Read value directly from the
preset table, 503
Preset
number
1 to 9 X axis to W axis
Group name, ID no. Number Index Meaning
